Press material FX501 extruded
Product Description
Plastic FX501 is a high performance engineering plastic, also known as polyester material. It has excellent heat resistance, chemical resistance, and mechanical strength, and is used in a wide variety of applications that require high strength and durability. In addition, FX501 has excellent electrical insulation properties and machinability to meet the manufacturing needs of complex shaped products.
Technical parameters and performance indices of FX501 phenolic glass fiber molding compound:
| Project | Indicator |
| Density.g/cm3 | 1.60～1.85 |
| Volatile content.% | 3.0～7.5 |
| Water absorption.mg | ≤20 |
| Shrinkage rate.% | ≤0.15 |
| Heat resistance (Martin).℃ | ≥280 |
| Tensile strength.Mpa | ≥80 |
| Bending strength.Mpa | ≥130 |
| Impact strength (no notch).kJ/m2 | ≥45 |
| Surface resistivity.Ω | ≥1.0×1012 |
| Volume resistivity.Ω•m | ≥1.0×1010 |
| Dielectric loss factor（1MHZ） | ≤0.04 |
| (Relative) dielectric constant（1MHZ） | ≤7.0 |
| Electrical strength.MV/m | ≥14.0 |
FX501 material is a thermosetting phenolic fiberglass molding compound with the following characteristics:
1. High heat resistance: FX501 material will not melt or deform at high temperatures, and is able to withstand temperatures up to 200℃.
2. Non-toxic: FX501 material is basically non-toxic after molded into products, which meets the requirements of environmental protection.
3. Corrosion resistance: FX501 material has good corrosion resistance and can resist the erosion of acid, alkali and other chemical substances.
4. High mechanical strength: FX501 material has high mechanical strength and can withstand large pressure and weight.
FX501 material is widely used in the following fields:
1. Electronic and electrical appliances: FX501 material has good insulating properties and high temperature resistance, which is suitable for manufacturing electronic and electrical parts.
2. automobile industry: FX501 material has high strength and heat resistance, suitable for manufacturing automobile parts.
3. chemical industry: FX501 material has good corrosion resistance, suitable for manufacturing chemical equipment and pipelines.
4. Construction industry: FX501 material has high strength and heat-resistant performance, suitable for manufacturing construction materials and decorative materials.
