Product Description

3526 Phenolic Laminated Cotton Cloth Tube is a heavy-duty electrical and mechanical insulation material crafted from high-tensile, scouring desizing cotton fabric thoroughly impregnated with premium phenolic resin. Compared to paper-based tubes, this cotton cloth laminate offers significantly higher longitudinal tensile strength, excellent impact resistance, and lower water absorption (≤4%).

With a superior thermal stability rating of ≥130° C, it is specifically engineered for structural components that demand robust mechanical loads and complex precision machining.

1, Structure (composition): scouring desizing cotton cloth, phenolic resin;

2, Performance (summary): high longitudinal tensile strength and low water absorption;

3, Application (purpose): suitable for insulation structure parts with high mechanical strength requirements and bearing a variety of mechanical processing;

4, Minimum inner diameter ɸ10; maximum outer diameter ɸ800; minimum wall thickness: 2mm;
