Products >> Assembled Roving For SMC

  • /UploadFiles/2014/0/2014011709494941202.jpg


NAME:Assembled Roving for SMC

Number:
  • Assembled Roving for SMC is compatible with unsaturated polyester, vinyl ester resin, delivering good dispersion after chopping, low fuzz, fast wet out and low static.
    Its end use applications cover:
    • Automotive parts: bumper, rear cover box, car door, headliner;
    • Building & construction industry: SMC door, chair, sanitary ware, water tank, ceiling;
    • Electronic & electrical industry: a variety of parts.
    In recreation industry: a variety of apparatus.
Features




Product Description



Assembled Roving for SMC is compatible with unsaturated polyester, vinyl ester resin, delivering good dispersion after chopping, low fuzz, fast wet out and low static.

Product Features:

1) Good dispersion after chopping

2) Low fuzz

3) Fast wet out

4) Low static



     Roving-13


Product Information
Item Linear Density Resin Compatibility Features End Use
BHSMC-01A 2400,4392 UP,VE

for general pigmentable

SMC product

truck parts, water tanks,
door sheet and electrical parts
BHSMC-02A 2400,4392 UP,VE

high surface quality,

low combustible content

ceiling tiles, door sheet
BHSMC-03A 2400,4392 UP,VE excellent hydrolysis resistance bathtub
BHSMC-04A 2400,4392 UP,VE

high surface quality,

high combustible content

bathroom equipment
BHSMC-05A 2400,4392 UP,VE good choppability,
excellent dispersion, low static

automotive bumper

and headliner



Identification
Type of Glass E
Assembled Roving R
Filament Diameter, μm 13,14
Linear Density, tex 2400, 4392



Technical Parameters
Linear Density  (%) Moisture Content  (%) Size Content  (%) Stiffness (mm)
ISO1889 ISO3344 ISO1887 ISO3375
±5 ≤0.10 1.25±0.15 160±20



            8 SMC-e.jpg




Shipping & Storage

Unless otherwise specified, the fiberglass products should be in dry, cool and moisture-proof area. The room temperature and humidity should be always maintained at 15℃~35℃ and 35%~65%. It is best if the price is used within 12 months after production date. The fiberglass products should remain in their original packaging until just prior to user.

To ensure safety and avoid damage to the product, the pallets not be stacked more than three layers high. When the pallets are stacked in 2 or 3 layers, special care should be taken to correctly and smoothly move the top pallet.

Packaging

The product can be packed on pallet or in small cardboard boxes.

Package height mm (in) 260(10) 260(10)
Package inside diameter mm(in) 100(4) 100(4)
Package outside diameter mm(in) 270(10.6) 310(12.2)
Package Weight kg(lb) 17(37.4) 23(50.7)



Number of layers 3 4 3 4
Number of doffs per layer 16 12
Number of doffs per pallet 48 64 36 48
Net Weight per pallet kg(lb) 816(1797.3) 1088(2396.5) 828(1825.4) 1104(2433.9)



Pallet Length mm(in) 1120(44) 1270(50)
Pallet Width mm(in) 1120(44) 960(37.8)
Pallet height mm(in) 940(37) 1180(46.5) 940(37) 1180(46.5)

                                 Assembled Roving-packing

LOADING

Application

1) Automotive parts: bumper, rear cover box, car door, headliner;

2) Building & construction industry: SMC door, chair, sanitary ware, water tank, ceiling;

3) Electronic & electrical industry: a variety of parts.

4) In recreation industry: a variety of apparatus.
